LG dryer model number decoder, explained

When selecting an LG dryer or searching for information about a specific device by model number, it is essential to understand the limitations inherent in the model identification system. Although the model number contains information about the dryer’s series and design features, it does not indicate the year of the first release. This is due to industry practice: the production of a dryer model occurs over several years. Successful models can be produced for seven years, typically remaining in production for approximately five years.

Additionally, it’s common practice to use the same chassis to manufacture dryers for various regions, even though they might be assigned different model numbers. As a result, the structure of these model numbers can vary from one region or country to another.

Dryer model number decoding for the USA and Canada

In the United States and Canada, a notable characteristic of dryers is the widespread use of natural gas models. As a result, two types of dryers are commonly available: those that use electricity and those that use gas for drying. This distinction is often reflected in the dryer’s model number. For dryers in this region, the model number is composed of four distinct information blocks, each conveying specific details. To better understand this, refer to the figure below.

1. Device type identification.
2. Technical information block.
3. Rating block, model series, modification.
4. The block design usually matches the color of the device.

Example of detailed LG dryer model number decoding for USA

Let’s decipher the LG DLEX5500V dryer model number as an example, dryers with these model numbers are offered in North America.

• Let’s break down the LG DLEX5500V dryer model number as an example, commonly found in North America.
• D – Dryer
• L – Appliance type, specifically laundry care.
• E – Indicates the dryer uses electricity for heating. Alternatively:
  • G – Denotes a gas dryer that must be connected to a gas line.
• Additional codes include:
• HC(C) – Heat Condenser, where the dryer is equipped with a small compressor that cools a coil. A pump then blows air through the coil, causing moisture to condense and drain into a tank. These models, which use either gas or electricity for heating, do not increase indoor humidity and are ideal for regions with high humidity.
• Here’s a quick guide to these symbols:
• DLE – Electric dryer; moisture is removed by a fan and vented into the room.
• DLEX – Electric dryer with a steam function; after drying, the laundry is steamed to eliminate bacteria and reduce wrinkles, making ironing easier.
• DLEC – Electric dryer with a condenser; moisture is collected in a container.
• DLG – Gas dryer; moisture is vented into the room.
• DLGX – Gas dryer with a steam function.
• DLGC – Gas dryer with a condenser.
• The remaining digits and letters provide further details:
• 5 – Series number; the higher the number, the more features the dryer offers.
• 5 – Model number.
• 00 – Appliance specification.
  • 00 – Electric dryer.
  • 01 – Gas dryer.
• V – Housing color (design)
  • W – white
  • B – black
  • C – graphite steel
  • M – medium black
  • K – black stainless steel
  • L – platinum black

Dryer model numbers Europe

In Europe, gas-fired dryers are rarely used, resulting in more uniform model numbers across the continent, though they may still vary by country. Unlike in North America, the model numbers of LG dryers in Europe offer little useful information. Instead, they function primarily as simple identifiers for the units, reflecting the fact that dryers are not as prevalent in Europe as they are in North America.

Dryer model numbers for UK explanation

In the UK, the LG dryer model number is fairly minimal and can be deciphered as follows, for example, model number FDC309W.

• F – front loading
• D – dryer
• C – modification, something has been changed in the dryer, but the same platform is used.
• 3 – series, the higher the number, the greater the functionality.
• 0 – model
• 9 – maximum load of laundry
• W – color
  • W – white
  • B – black
  • S – graphite

LG dryer model number in Germany: meaning of the symbols

The system of LG dryer model codes in Germany is quite confusing, with two types of model codes in use. For example, RT80V9W, V3R08T, and RT90V9W may refer to the same dryer model with only minor differences. It is nearly impossible to glean much information from the model number beyond the maximum load, which is largely irrelevant since few people weigh their laundry before drying. However, the figure provides an example of how to decipher the model number.

In German dryer model numbers, you can find information about the maximum load and the model itself. Additionally, both versions of the codes include details about the design, such as the color of the dryer.
